Combilift C10000E Multi-Directional Forklift

Details

The Combilift C10000E electric multi-directional forklift is designed for the safe, space saving and productive handling of long and bulky loads.

Equipment Type
3 Wheel Electric Forklift Trucks / Forklifts

27 x 10-12 Rear Tire:
OD 27” / Width 10”

405 x 305 x 220 Front Tire (Solid Rubber):
OD 16” / Width 9”

AC Electric Pump Motor:
80V / 25 HP

AC Electric Traction Motor x 2:
80 V / 7 HP

Approach Angle:
45 °

Backward Tilt:
5 °

Battery Capacity:
80 V / 620 Ah

Capacity:
10,000 lbs

Departure Angle:
45 °

Fork Section:
2” x 6” x 53”

Forward Tilt:
3 °

Frame Opening :
55”

Freelift Height:
0”

Gradebility:
10%

Ground Clearance to Center of Wheelbase:
4¼”

Ground Clearance Under Mast:
6”

Height Mast Closed:
112”

Height Over Cab (without work lights):
96”

Length From Face of Fork:
45½”

Load Center Distance:
24”

Mast Travel:
57”

Max. (Mast raised):
192”

Max. Lift Height:
159”

Maximum Ground Speed:
6 mph

Minimum Outside Radius:
98”

Outside Spread of Fork Arms:
53”

Overall Length:
98”

Overhang Back:
5” x 5¼”

Overhang Front:
8¾”

Platform Height:
19”

Platform Length:
53”

Ramp Angle:
17 °

Standard Color:
Green & Gray

Track Front:
79¾”

Unladen Weight:
15,100 lbs

Wheelbase:
80½”

Width:
89”

  • Rubber Mounted Cabin
  • Load Sensing Steering
  • Curtis AC Software
  • 4 Way Lever Positioning of Wheels
  • 2 Wheel Drive
  • Multi-Directional Operation
  • AC Motor Technology
