Genie S-80 HF and S-85 HF Boom Lift
Details
The Genie® S-80 HF and S-85 HF boom lifts deliver the lifting performance and reach required for demanding applications on sensitive ground conditions. They help operators perform heavy-lifting tasks while minimizing ground impact on sand, turf, and other delicate surfaces.
A high-flotation design distributes machine weight more effectively across soft terrain to help protect sensitive surfaces during operation. Specialized tire configurations further reduce ground impact while allowing the Genie S-80 HF and S-85 HF boom lifts to maintain the reach, lifting capability, and productivity required on challenging jobsites.
Overview
This new generation of Genie HF booms retain the productivity features that enhance customers’ ability to get work done quickly, including:
- A virtual pivot primary boom that aligns the machine’s center of gravity for lower machine weight
- 35,500 lb (16,103 kg) on the Genie S-80 HF model
- 38,000 lb (17,237 kg) on the Genie S-85 HF model
- 4WD and positive traction drive maintains equal power to all drive wheels
- 45% grade-ability (stowed) for driving on slopes
- 160Ëš platform rotation and 360Ëš continuous rotation turntable for quick, precision positioning
- Equipment Type
- Aerial Lifts / Telescopic Boom Lifts
Max Working Height:Â
S-80 HF: 86 ft
S-85 HF: 91 ft
Max Horizontal Reach:Â
S-80 HF: 68 ft 6 in
S-85 HF: 72 ft 6 in
Below Ground Reach:
S-80 HF: 5 ft 6 in
S-85 HF: 8 ft 8 in
Platform Capacity:
Unrestricted: 600 lbs
Restricted: 1,000 lbs
Machine Width and Length:
S-80 HF: 8 ft 6 in x 37 ft 7 in
S-85 HF: 8 ft 6 in x 40 ft 7 in
- A virtual pivot primary boom that aligns the machine’s center of gravity for lower machine weight
- 35,500 lb (16,103 kg) on the Genie S-80 HF model
- 38,000 lb (17,237 kg) on the Genie S-85 HF model
- 4WD and positive traction drive maintains equal power to all drive wheels
- 45% grade-ability (stowed) for driving on slopes
- 160Ëš platform rotation and 360Ëš continuous rotation turntable for quick, precision positioning
Details
The Genie® S-80 HF and S-85 HF boom lifts deliver the lifting performance and reach required for demanding applications on sensitive ground conditions. They help operators perform heavy-lifting tasks while minimizing ground impact on sand, turf, and other delicate surfaces.
A high-flotation design distributes machine weight more effectively across soft terrain to help protect sensitive surfaces during operation. Specialized tire configurations further reduce ground impact while allowing the Genie S-80 HF and S-85 HF boom lifts to maintain the reach, lifting capability, and productivity required on challenging jobsites.
Overview
This new generation of Genie HF booms retain the productivity features that enhance customers’ ability to get work done quickly, including:
- A virtual pivot primary boom that aligns the machine’s center of gravity for lower machine weight
- 35,500 lb (16,103 kg) on the Genie S-80 HF model
- 38,000 lb (17,237 kg) on the Genie S-85 HF model
- 4WD and positive traction drive maintains equal power to all drive wheels
- 45% grade-ability (stowed) for driving on slopes
- 160Ëš platform rotation and 360Ëš continuous rotation turntable for quick, precision positioning
- Equipment Type
- Aerial Lifts / Telescopic Boom Lifts
