JLG 800AJ HC3 Boom Lift
Details
The JLG® 800 Series articulating boom lifts deliver the reach, capacity, and versatility needed to work around obstacles and access challenging elevated work areas. With exceptional outreach, a large working envelope, and a service-friendly design, they help maximize productivity on demanding jobsites.
The 800 Series helps operators work faster with JLG’s QuikStik® boom, reaching 80 ft in less than 50 seconds. With up to 53 ft of outreach, 32 ft of up-and-over reach, and a high-capacity platform option for up to three occupants and tools, it delivers exceptional access and productivity on demanding jobsites.
Key Specs
- Platform Height: 80 ft 4 in. / 24.5 m
- Platform Capacity – Restricted: 1000 lb / 453.59 kg
- Platform Capacity – Restricted 2: 750 lb / 340.19 kg
- Platform Capacity – Unrestricted: 660 lb / 299.37 kg
- Horizontal Outreach: 52 ft 4 in. / 15.95 m
Key Features
The JLG 800 Series HC3 boom lift helps crews work more efficiently at height with enhanced platform capacity, simplified operation, and improved operator awareness. Multiple capacity zones allow up to three workers and their tools in the platform, while automatic load sensing eliminates manual calibration requirements. An upgraded light panel and chassis tilt alarm further enhance visibility and confidence on the jobsite.
- Equipment Type
- Aerial Lifts / Telescopic Boom Lifts
Auxiliary Power:
12 Volts DC
Capacity – Fuel Tank:
39 gal. / 147.63 L
Engine Type – Diesel:
DEUTZ TD 2.9L Tier 4 Final 67 hp
Engine Type – Dual Fuel:
Ford MSG425 84hp
Axle Oscillation:
8 in. / 0.2 m
Drive Speed – 2WD:
3 mph / 4.83 km/h
Drive Speed – 4WD:
3 mph / 4.83 km/h
Grade-ability – 2WD:
30 %
Grade-ability – 4WD:
45 %
Platform Capacity – Restricted:
1000 lb / 453.59 kg
Platform Capacity – Restricted 2:
750 lb / 340.19 kg
Platform Capacity – Unrestricted:
660 lb / 299.37 kg
Swing:
360 Degrees
Swing Type:
Continuous
Turning Radius – Outside (2WS):
21 ft 6 in. / 6.56 m
Jib – Range of Articulation:
130 Degrees
Ground Clearance:
11 in / 0.28 m
Horizontal Jib Rotation:
0 Degrees
Horizontal Outreach:
52 ft 4 in. / 15.95 m
Platform Height:
80 ft 4 in. / 24.5 m
Up and Over Height:
26 ft / 7.91 m
Machine Weight:
37530 lb / 17023.32 kg
- More Flexibility at Height: With three working zones and enhanced capacity, up to three workers and tools can fit into the platform
- Increased Efficiency: A zero calibration automatic load sensing system eliminates the need to use external weights to calibrate the machine
- Enhanced Operator Experience: An upgraded light panel is more visible in the sun, while a chassis tilt alarm alerts the operator when the machine is on a slope that exceeds 5 degrees
- Model shown features optional SkyGlazier® Package
