JCB 407 Wheel Loader

Details

The 407 is a highly productive wheel loader with the compact dimensions, performance, versatility, agility and uncompromised productivity you’d expect from JCB. It’s fit with a 48 kW engine that produces 300 Nm of torque, powering a 2-speed hydrostatic transmission. With a load over height of 2991 mm.

This wheel loader also features superior quality components, plenty of comfort and ergonomics, excellent build quality, stringent safety levels and straightforward serviceability.

In short, it’s a perfect tool carrier on construction sites.

Equipment Type
Construction & Ag / Wheel Loaders

Engine

Type:
4 stroke, Electronic Common Rail

Model:
JCB Diesel by Kohler – KDI 2504 TCR

Capacity:
2.482 liters

Aspiration:
Turbocharged

Cylinders:
4

Max gross power (SAE J1995/ISO 14396):
64 hp (48 kW) @ 2200rpm

Max torque:
221 lbf (300 Nm)

Emissions:
Stage IIIB & T4F



Transmission

Type:
Hydrostatic

Model:
Rexroth A6VM – 2 speed

Model (high speed option):
Rexroth A6VM – 3 speed

Low range:
3.75 mph (6 kph)

High range:
11.1 mph (18 kph)

High speed (high speed option):
21.7 mph (35 kph)



Axles

Type:
Straight beam

Make and model:
Dana Spicer 111

Chassis angle oscillation:
±10°



Dimensions

Overall length:
16′ 10″ (5,133 mm)

Axle to pivot pin:
3′ (906 mm)

Wheelbase:
6′ 11″ (2,100 mm)

Axle to counterweight face:
4′ 2″ (1,268 mm)

Ground clearance:
1′ (313 mm)

Width over cab:
4′ 10″ (1,468 mm)

Width over tires:
5′ 8″ (1,727 mm)

Wheel track:
4′ 7″ (1,390 mm)

Height over cab:
8′ 2″ (2,500 mm)

Front axle weight:
3,075 lbs (1,395 kg)

Rear axle weight:
8,087 lbs (3,668 kg)

Total weight:
11,162 lbs (5,063 kg)

Inside turn radius:
6′ 7″ (2,010 mm)

Maximum turn radius over bucket:
13′ 8″ (4,160 mm)

Maximum radius over tire:
12′ 6″ (3,800 mm)

Maximum radius across tires:
6′ 1″ (1,864 mm)

Articulation angle:
±40°

  • Stage IIIB/ Tier 4i-compliant JCB Diesel by Kohler engine
  • 48 kW of power and 300 Nm of torque
  • Hydrostatic drive for easy operation
  • Great all-round visibility and superb operator comfort
  • Heavy-duty versatile articulated steering system with sideshift
  • Easy to service and extremely safe to operate
  • Full cab with heater, A/C and 365/70 R18 Dunlop SPT9 tires, or canopy with 12.5 x 18 Camso tires
  • 3-spool manual hydraulics
  • Standard front axle with LSD rear
  • Tool carrier parallel lift loader arm geometry
  • Skid steer hitch with auxiliary hydraulics
  • Front and rear work lights
