Skyjack SJ519 TH Telehandler
Details
Skyjack SJ519 TH telehandlers are designed with all major service points easily accessible, limiting downtime and increasing our customers’ utilization.
FLEXCAB
The SJ519 TH telehandlers feature an innovative cab design that allows fleet operators to easily convert between open and enclosed cabs with simple hand tools, providing increased flexibility for fleet movement and fast response to customer demands. Easily sourced flat glass panels with no custom curved profiles and a bolt-on/bolt-off window retention system ensures minimal downtime and incurred costs for repairing damaged glass in the field.
AXLDRIVE
An axle-based drive system with an operator controlled locking differential on the rear axle and limited slip differential on the front axle. This drive system has been proven as durable, low maintenance, and capable of navigating any job site terrain.
- Equipment Type
- Construction & Ag / Telehandler/Articulated Telescopic
Maximum Lift Capacity:
5,500 lbs (2,495 kg)
Maximum Lift Height:
19’ 1” (5.82 m)
Rated Lift Capacity @ Maximum Height:
4,400 lbs (1,996 kg)
Maximum Forward Reach:
11’ 1” (3.38 m)
Rated Lift Capacity @ Maximum Reach:
2,000 lbs (907 kg)
Overall Length – Less Forks:
13’ 5” (4.09 m)
Overall Height – Stowed:
6’ 4” (1.93 m)
Overall Width:
5’ 11.5” (1.81 m)
Ground Clearance:
11” (27.94 cm)
Turning Radius – Outside:
125” (3.17 m)
Operating Weight ‡:
10,500 lbs (4,763 kg)
Engine:
74hp/184 lb-ft Deutz TCD 2.2L T4F
Max Travel Speed – Forward:
15mph (24 km/h)
Drawbar Pull:
8,700 lbs
Breakout Force:
10,600 lbs
Transmission:
Hydrostatic, 1 F/R
Axles:
Dana
Steering:
3 Mode (Front Wheel, 4 Wheel, Crab)
Tires:
Pneumatic 12 x 16.5 12PR Grip Lug
Fuel Tank Capacity:
15.1 gal. (57 L)
Hydraulic Reservoir:
18.7 gal. (70 L)
- 18 GPM Auxiliary hydraulics with hydraulic flow control valve
- Quick attach carriage mount
- Rear and side window
- Suspension seat
- Single multifunction pilot operated joystick control
- In-cab engine multifunction display
- Hydraulic test ports
- Lockable in-cab storage box
- Steel engine bay cowling
- Steel component and access covers
- 2-Year Gold Leaf Warranty (5-year structural warranty)
