Pro XD Mid-Size Gas Utility Vehicle

Engine & Drivetrain

Air Intake:
Side Air Intake

Cooling:
Liquid

Cylinders Displacement:
567cc

Drive System Type:
Selectable 4×4

Engine Type:
ProStar 570 DOHC Gas Motor

Fuel System/Battery:
Electronic Fuel Injection

Horsepower:
39.5 HP

Maintenance Interval:
200 Hours (50 Hour initial)

Top Speed:
Adjustable up to 40 mph (64 km/h)

Transmission/Final Drive:
Automatic PVT H/L/N/R/P; Shaft



Dimensions

Bed Box Dimensions (L x W x H):
33.3″ x 48.7″ x 12.3″ (84.6 x 123.7 x 31.2 cm)

Box Capacity:
500 lb (226 kg)

Estimated Dry Weight:
1,218 lb (552 kg)

Fuel Capacity:
9.5 gal (36.0 L)

Ground Clearance:
11.5 in (29 cm)

GVWR:
2,255 lb (1023 kg)

Hitch Towing Rating:
1,500 lb (680 kg)

Overall Vehicle Size (L x W x H):
108 x 56 x 74 in. (274.3 x 142.2 x 188 cm)

Payload Capacity:
946 lb (429 kg)

Person Capacity:
2

Turning Radius:
12.3 ft (3.75 m)

Wheelbase:
73 in (185.4 cm)



Brakes

Front/Rear Brakes:
4-Wheel Hydraulic Disc

Parking Brake:
Park In-Transmission



Specifications

Adjustable Driver Seat:
Not Equipped

Cargo System:
Lock & Ride

Hitch Type:
Standard 2 in (5.08 cm) Receiver

Instrumentation:
All Digital Gauge, Speedomoter, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Diff Lock Indicator, Clock, Clutch Belt Slip Warning, Low Oil Pressure Indicator, Seat Belt Indicator

Lighting:
55W Headlight, LED Taillamps

Other Standard Features:
Horn, Backup Alarm, Password protected, electronically adjustable speed limiting.

Seat Covering:
Kevlar®-Backed Vinyl (Grey)

Tilt Steering:
Standard



Tires/Wheels

Electronic Power Steering:
Optional

Front Tires:
25 x 9.00-12; Wanda Crawler P3057

Hubs:
Front: Ductile Iron; Rear: Aluminum

Rear Tires:
25 x 9.00-12; Wanda Crawler P3057

Wheels:
12 x 6 HD Steel – Gloss Black



Suspension

Front Suspension:
MacPherson Strut 9″ (22.9 cm) Travel

Rear Suspension:
Dual A-Arm, IRS 10″ (25.4 cm) Travel
