JCB S2632E Electric Scissor Lift
Details
The JCB S2632E electric scissor lift combines compact maneuverability with increased working height for greater jobsite versatility. Designed for indoor and outdoor applications, it delivers the safety, reliability, and productivity features found throughout the JCB Access range. Its higher lift capability helps operators complete elevated tasks efficiently while maintaining the performance and ease of use needed.
The JCB S2632E comes standard with power to platform, helping operators use tools and equipment more efficiently while working at height. Like all JCB Access electric scissor lifts, the S2632E combines safety, productivity, and easy operation with service-friendly design features that help maximize uptime.
- Equipment Type
- Aerial Lifts / Scissor Lifts for Sale
Load Capacity:
550 lb (250 kg)
Max. Platform Height:
Indoor: 26 ft (7.92 m)
Outdoor: 19 ft (5.8 m)
Max. Working Height:
32 ft (9.92 m)
Platform Size (L x W x H):
89 in x 32 in x 43 in
Extension Outreach:
35 in (0.9 m)
Overall Length (Stowed):
7 ft 10 in (2.39 m)
Overall Width (Stowed):
2 ft 8.5 in (0.83 m)
Overall Height (Stowed, Guardrail Folded):
6 ft 5 in (1.96 m)
Overall Height (Stowed, Guardrail Unfolded):
7 ft 8 in (2.33 m)
Overall Weight:
5,124 lbs (2,324 kg)
Max. Platform Occupants:
Indoor: 2 people
Outdoor: 1 person
Max. allowable slope (front to back / side to side):
3° / 1.5°
Ground Clearance:
4 in (0.1 m)
Wheelbase:
73 in (1.85 m)
Turning Radius:
Outside: 6 ft 11 in (2.1 m)
Inside: 0
Gradeability:
25%
Max Driving Speed:
Stowed: 2.8 mph ( 4.5 km/h)
Raised: 0.5 mph (0.8 km/h)
Raising Speed (Loaded):
28-34 seconds
Lowering Speed (Loaded):
32-38 seconds
Solid Tyre Dimensions:
15 ins x 5 ins
Hydraulic Tank Volume:
3.2 gal (12 L)
Hydraulic System Volume:
4 gal (15 L)
Hydraulic System Pressure:
24.8 MPa
Battery – Ah @ 20h:
6V x 4 (225)
Power Unit:
24 V
Input Voltage of Charger:
100-240V
- Featuring folding rails for easy passage through standard doorways, and a waterproof cover on the platform’s power outlet to shield it from the elements. The S2632E is ideal for indoor and outdoor working.
- The S2632E has a two-person platform capacity indoors: Twice the workforce, twice the productivity.
- Access the controller cradle from any side of the basket, as well as on the ground, and drive the machine at full height for effortless operation.
- Stay on top of power levels, to minimize unexpected downtime, with the battery charger indicator.
- Our smart hose and harness routing is engineered to help prevent hose chaffing or snagging as the platform moves up and down.
- Simple, safe entry and exit with an ergonomic door handle that can be used even with gloved hands, and a ladder with familiar excavator-style steps.
- Simple controls for all skill levels with an ergonomic controller cradle suitable for left and right-handed use, plus a foot pedal for easy deck extension.
- Simple power tool connection with a waterproof power outlet inside the basket.
- Simple maneuvering and loading with a front-mounted winch point and large tie down points for easy transportation.
- Simple battery isolation with a large handle allows for quick and easy battery disconnection, even while wearing gloves.
- The Pothole protection system ensures stability by preventing the lift scissor from raising until the pothole protection struts are fully deployed.
- Fully proportional raise and drive controls, combined with a creep speed mode, allow for highly accurate machine handling.
- Advanced tilt sensors stop elevation when the operating slope exceeds 1.5 degrees side-to-side or 3 degrees front-to-back, with a clear warning displayed on the platform controller.
