JCB S3246E Electric Scissor Lift
Details
The JCB S3246E scissor lift delivers the platform capacity, reliability, and performance required for indoor maintenance and construction applications. It supports two operators and their tools while providing working heights above 32 feet.
A roller-supported deck extension allows operators to access work areas efficiently, even at maximum height. Industry-standard components simplify service and replacement, helping reduce downtime and support lower ownership costs throughout the life of the machine.
- Equipment Type
- Aerial Lifts / Scissor Lifts for Sale
Load Capacity:
705 lb (320 kg)
Max. Platform Height:
31 ft 9 in (9.68 m)
Max. Working Height:
37 ft 9 in (11.68 m)
Platform Size (L x W x H):
89 in x 46 in x 43 in
Extension Outreach:
35 in (0.9 m)
Overall Length (Stowed):
7 ft 10 in (2.39 m)
Overall Width (Stowed):
3 ft 10.5 in (1.18 m)
Overall Height (Stowed, Guardrail Folded):
6 ft 1 in (1.86 m)
Overall Height (Stowed, Guardrail Unfolded):
8 ft 2 in (2.48 m)
Overall Weight:
6,287 lbs (2,852 kg)
Max. Platform Occupants:
Indoor: 2 people
Outdoor: 1 person
Max. allowable slope (front to back / side to side):
3° / 1.5°
Ground Clearance:
4 in (0.1 m)
Wheelbase:
73 in (1.85 m)
Turning Radius:
Outside: 7 ft 8 in (2.35 m)
Inside: 0
Gradeability:
25%
Max Driving Speed:
Stowed: 2.8 mph ( 4.5 km/h)
Raised: 0.5 mph (0.8 km/h)
Raising Speed (Loaded):
49-54 seconds
Lowering Speed (Loaded):
40-46 seconds
Solid Tyre Dimensions:
15 ins x 5 ins
Hydraulic Tank Volume:
3.2 gal (12 L)
Hydraulic System Volume:
4.2 gal (16 L)
Hydraulic System Pressure:
24.8 MPa
Battery – Ah @ 20h:
6V x 4 (240)
Power Unit:
24 V
Input Voltage of Charger:
100-240V
- Two-person platform capacity, so whether you’re indoors or outdoors, you’ll get twice the productivity
- Control cradle design allows for use on all sides of the basket and enables easy operation from both in the basket and on the ground.
- Stay on top of power levels, to minimize unexpected downtime, with the battery charger indicator.
- Our smart hose and harness routing is engineered to help prevent hose chaffing or snagging as the platform moves up and down.
- Simple entry and exit with the ergonomic door handle can be operated even with gloved hands, and familiar excavator-style steps make entry simple.
- Suitable for left and right-handed use, the ergonomic controller works alongside a foot pedal for easy deck extension, making controls simple for all skill levels.
- Easily connect tools with the waterproof power outlet
- Transportation is easy with a front-mounted winch point and large tie down points
- Simple battery isolation with a large handle allows for quick and easy battery disconnection, even while wearing gloves.
- Protective features like warning light protection, motor protection plates, and wear pads between scissor sections are designed to prevent metal-on-metal damage.
- Individually-fused circuits enable precise troubleshooting, ensuring that a single fuse failure impacts only the specific circuit rather than disabling the entire machine.
- Unique JCB features, such as wear pads on the battery and hydraulic doors prevent them from sagging over time by supporting their weight.
