JCB S4046E Electric Scissor Lift
Details
The JCB S4046E Electric Scissor Lift combines elevated performance with operator-focused safety and productivity features. As part of the JCB Access range, it delivers reliable electric-powered lifting capability for a wide variety of indoor and outdoor applications.
Equipped with standard power-to-platform functionality and an easy-to-use deck extension, the S4046E helps operators work efficiently even at its maximum platform height of 39 ft. Its user-friendly design, built-in safety features, and simplified serviceability make it a productive and dependable solution for elevated access tasks.
- Equipment Type
- Aerial Lifts / Scissor Lifts for Sale
Load Capacity:
705 lb (320 kg)
Max. Platform Height:
Indoor: 39 ft (11.9 m)
Outdoor: 25 ft (7.62 m)
Max. Working Height:
45 ft (13.9 m)
Platform Size (L x W x H):
89 in x 46 in x 43 in
Extension Outreach:
35 in (0.9 m)
Overall Length (Stowed):
7 ft 10 in (2.39 m)
Overall Width (Stowed):
3 ft 10.5 in (1.18 m)
Overall Height (Stowed, Guardrail Folded):
6 ft 6 in (1.98 m)
Overall Height (Stowed, Guardrail Unfolded):
8 ft 6 in (2.60 m)
Overall Weight:
7,211 lbs (3,271 kg)
Max. Platform Occupants:
Indoor: 2 people
Outdoor: 1 person
Max. allowable slope (front to back / side to side):
3° / 1.5°
Ground Clearance:
4 in (0.1 m)
Wheelbase:
73 in (1.85 m)
Turning Radius:
Outside: 7 ft 8 in (2.35 m)
Inside: 0
Gradeability:
25%
Max Driving Speed:
Stowed: 2.8 mph ( 4.5 km/h)
Raised: 0.5 mph (0.8 km/h)
Raising Speed (Loaded):
62-67 seconds
Lowering Speed (Loaded):
46-54 seconds
Solid Tyre Dimensions:
15 ins x 5 ins
Hydraulic Tank Volume:
3.2 gal (12 L)
Hydraulic System Volume:
4.8 gal (18 L)
Hydraulic System Pressure:
24.8 MPa
Battery – Ah @ 20h:
12V x 4 (150)
Power Unit:
24 V
Input Voltage of Charger:
100-240V
- Advanced integrated safety features such as platform stability, secure guardrails and advanced braking systems.
- Fully proportional raise and drive controls with creep speed mode allows for precise machine movements.
- Pothole protecting system only allows the machine to raise once it is fully deployed.
- Industry standard components allow seamless integration into existing rental fleets with industry.
- Features such as the full pivot boss design on scissor pack, weld designs and motor protection plates are all designed using JCB’s 75 years of engineering and manufacturing experience.
- Automotive style foot pedal to release the extension deck provides an intuitive and ergonomic operation.
- Control cradle design allows for use on all sides of the basket and enables easy operation from both in the basket and on the ground.
- Waterproof cover on the power to platform outlet protects the socket, ensuring it is ready to use.
- Easy-to-use spring clips allow the platform rails to fold down for maneuvering in confined spaces.
- Simple to view charge level indicator keeps you informed of battery status.
- Platform outlet in the basket makes connecting power tools easy.
- Roller design and foot pedal for the extension deck make it easy to extend or retract, even at height.
- Ergonomically designed door handle makes for easier and safer entry, even with gloved hands.
- Ergonomic controller cradle for both left and right use and an automotive style foot pedal for deck extension.
- Large handle on the battery isolator means it can be operated whilst wearing gloves.
